MRCOOL Advantage 5th Gen 18,000 BTU Single Zone Mini Split Complete System with 16 Ft. Line Set, 230V, Wall Mounted (A-18-HP-230D-O)
MRCOOL Authorized Dealer - Warranty Included
Fast and FREE Shipping! (some exceptions apply)
Easy 30-Day Returns
No Sales Tax (except some states)
Questions? Call us (307) 323-3460 or live chat
MRCOOL Authorized Dealer - Warranty Included
The MRCOOL® 5th Generation 18K BTU Advantage Mini-Split delivers powerful, energy-efficient heating and cooling for spaces up to 800 sq. ft. Ideal for larger rooms, open layouts, or multi-use area. This system includes a sleek, WiFi-enabled indoor air handler and a high-performance outdoor condenser. With eco-friendly R-454B refrigerant, smart controls, and quiet operation, the Advantage Bundle offers reliable year-round comfort with a professional-grade finish.
| Air Handler Model | A-18-HP-WMAH-230D-O |
| Air Handler Net Dimension (WxDxH) | 37.99 x 8.46 x 12.56 inch |
| Air Handler noise level (Turbo/Hi/Mi/Lo/Si) | 50.5/45/36/24/19 |
| Air Handler Minimum Circuit (Disconnect) | 3.0 A |
| Air Handler Maximum Fuse (Breaker) | 15.0 A |
| Air Handler Net/Gross Weight | 24.47/32.63 Lbs |
| Condenser Model | A-18-HP-C-230D-O |
| Condenser Net Dimension (WxDxH) | 31.69 x 12.99 x 21.81 inch |
| Condenser noise level (Hi) | 56 dB (A) |
| Condenser Minimum Circuit (Disconnect) | 15.0 A |
| Condenser Maximum Fuse (Breaker) | 20.0 A |
| Condenser Net/Gross Weight | 72.31/78.48 Lbs |
| Cooling Capacity | 18000 BTU/h |
| SEER2 | 19.2 BTU/w |
| EER2 | 10.8 BTU/w |
| Heating Capacity | 18800 BTU/h |
| HSPF2-4 | 9.3 BTU/h |
| HSPF2-5 | 7.5 BTU/h |
| Max Coverage Area* | Up to 800 |
| Power Supply | 208-230V-60Hz. 1Ph |
| †Refrigerant R-454B | 40.57 |
| Piping Size Liquid side/Gas side | 1/4”-1/2" |
| Brochure |
| Install Manual |
| Performance Data |
| Remote Manual |
| Service Manual |
| Warranty |
| Accessory Manual |
